Conforms to British Standard BS 3621:2004 and meets the tough criteria laid down by the insurance companies and the Police (Secure By Design)
Features an integral cylinder pull which protects the cylinder from being drilled
The cylinder has over 30,000 key variations and comes with a 20mm bolt throw for greater security and strength.
Finish
Matt Black
Dimensions
AVAILABLE IN TWO SIZES
44896.1
44896.2
Dimension On Diagram
Backset
40mm
60mm
A
Case Width
70mm
90mm
B
Case Height
86mm
86mm
C
Case Depth
33mm
33mm
D
Lever Projection From Case
25.5mm
25.5mm
E
Cylinder Height
83mm
83mm
F
Cylinder Width
50mm
50mm
G
Important Info Before You Buy
For use on inward opening doors only
Night latch can be dead-locked (double locked) This is done from the INSIDE by a full turn of the key
Double locks from inside, so if some one were to break the glass in a front door or a near by window they can't unlock the night latch with out the use of the key
Latch bolt is withdrawn by handle from inside and by turn of key from outside.
Bolt can be held back by pushing the button on lock case, then released by turning the handle up or down
The main lock bolt €œautomatically€ deadlocks, when the door is closed this makes the use of a credit card to force entry virtually impossible
