Flush Fitting Ring Style Operational Door Handle - Polished Brass (Lacquered)
Catalogue Number:
20801
Manufactured in England to high architectural quality in solid brass, the inset design is ideal for use on doors that need to fold back against a wall. This item has a highly polished, shiny finish.
Designed to work with a tubular latch such as our TLS heavy duty latch, this item can be used as a working door handle. There is an 8mm follower built into back of the ring handle to suit a UK standard 8mm x 8mm spindle. This item is designed to be morticed (cut) into the face of a door so it sits flush with the surface.
This product is available in three sizes - 65mm x 65mm / 75mm x 75mm / 90mm x 90mm
Designed to work with a tubular latch such as our TLS heavy duty latch, this item can be used as a working door handle. There is an 8mm follower built into back of the ring handle to suit a UK standard 8mm x 8mm spindle. This item is designed to be morticed (cut) into the face of a door so it sits flush with the surface.
This product is available in three sizes - 65mm x 65mm / 75mm x 75mm / 90mm x 90mm
This item is not held in stock and is only made to order, hence the 3-4 week lead time. If you're looking for a product of the highest quality, it's well worth the wait.
Size Details
| Item Code | Height (A) | Width (B) | Recess Diameter (C) | Recess Depth (D) | Backplate Thickness - (E) | Ring Pull Size (Internal Dimension) - (F) |
|---|---|---|---|---|---|---|
| 20801.1 | 65mm | 65mm | 61mm | 12mm | 3mm | 32mm |
| 20801.2 | 75mm | 75mm | 71mm | 12mm | 3mm | 36mm |
| 20801.3 | 90mm | 90mm | 85mm | 12mm | 3mm | 45mm |
Base Material
- Made from solid brass.
Finish Details
- Polished brass - highly polished, shiny finish.
- This item has been lacquered to help protect and maintain the shiny brass finish.
Alternative Finishes Available
- Antique brass
- Polished chrome
- Polished nickel
- Satin chrome
- Satin nickel
Fixings
- This handle is fitted via 4 x countersunk wood screws through the face of the backplate.
- Supplied with matching wood screws
Usage
- If fitting two flush pulls to a door (one either side) in conjunction with a tubular latch the minimum thickness door required is 44mm.
- Suitable for internal or external use.
Unit Of Sale
- This item is sold individually - (Each)
| Item | 20801 |
|---|---|
| Item Code | 20801 |
| Finish | Polished Brass (Lacquered) |
| Sold Per | Each - (Individually) |
| Availability | Made to order product - please allow 5-6 weeks for delivery |
Made to order product - please allow 5-6 weeks for delivery
-
