Knurled Design Lever Door Handles On Round Rose - Suitable For Use On FD30 / FD60 Fire Doors - Matt Black

Catalogue Number:

49220

Grouped product items
Product Name	Qty
49220.1 - Knurled Design Lever Door Handles On Round Rose - Tested For Use With FD30 / FD60 Fire Doors - Matt Black - Pair Short Description: 1 x pair of lever handles only £33.86 £28.22
49220.2 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Latch And Hinge Pack - To Suit 35mm Thick Non Locking Doors Short Description: Suitable for use on 35mm thick internal doors, items included within this door pack are: 1 x pair of door handles - matt black 1 x heavy duty tubular latch - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 3 x ball bearing hinges - 76mm x 50mm - matt black 1 x tubular latch - 76mm case depth (57mm backset) 3 x hinges - 76mm x 50mm £53.93 £44.94
49220.3 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Latch And Hinge Pack - To Suit 44mm Thick Non Locking Doors - FD30 Fire Rated Short Description: Suitable for use on 44mm thick FD30 fire rated internal doors, items included within this door pack are: 1 x pair of door handles - matt black 1 x heavy duty tubular latch - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 1 x intumescent kit for tubular latch 3 x fire rated ball bearing hinges - 102mm x 76mm - CE / UKCA Marked - fire rated - matt black 6 x intumescent hinge pad liners £78.36 £65.30
49220.4 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Bathroom Lock & Hinge Pack - To Suit 35mm Thick Doors With Bathroom Turn & Release Locking Short Description: Suitable for use on 35mm thick internal doors, items included within this door pack are: 1 x pair of door handles - matt black 1 x bathroom turn and release set - matt black 1 x heavy duty bathroom mortice lock - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 3 x ball bearing hinges - 76mm x 50mm - matt black £98.34 £81.95
49220.5 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Bathroom Lock & Hinge Pack - To Suit 44mm Thick Doors With Bathroom Turn & Release Locking Short Description: Suitable for use on 35mm thick internal doors, items included within this door pack are: 1 x pair of door handles - matt black 1 x bathroom turn and release set - matt black 1 x heavy duty bathroom mortice lock - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 3 x fire rated ball bearing hinges - 102mm x 76mm - CE / UKCA Marked - fire rated - matt black £109.91 £91.59
49220.6 - Knurled Design Lever Door Handles On Round Rose - Matt Black - 3 Lever Lock & Hinge Pack - To Suit 35mm Thick Key Locking Doors Short Description: Suitable for use on 35mm thick internal doors, items included within this door pack are: 1 x pair of door handles - matt black 2 x standard profile escutcheon key hole covers - matt black 1 x heavy duty 3 lever mortice sash lock - 76mm case depth CE / UKCA Marked - fire rated - matt black 3 x ball bearing hinges - 76mm x 50mm - matt black £92.15 £76.79
49220.7 - Knurled Design Lever Door Handles On Round Rose - Matt Black - 3 Lever Lock & Hinge Pack - To Suit 44mm Thick Key Locking Doors - FD30 Fire Rated Short Description: Suitable for use on 44mm thick FD30 fire rated internal doors, items included within this door pack are: 1 x pair of door handles - matt black 2 x standard profile escutcheon key hole covers - matt black 1 x heavy duty 3 lever mortice sash lock - 76mm case depth CE / UKCA Marked - fire rated - matt black 1 x intumescent kit for 3 lever sash lock 3 x fire rated ball bearing hinges - 102mm x 76mm - CE / UKCA Marked - fire rated - matt black 6 x intumescent hinge pad liners £123.48 £102.90
49220.8 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Euro Profile Lock & Hinge Pack - To Suit 35mm Thick Key Locking Doors With Internal Thumbturn Short Description: Suitable for use on 35mm thick internal doors, items included within this door pack are: 1 x pair of door handles - matt black 2 x euro profile escutcheon key hole covers - matt black 1 x heavy duty euro profile mortice sash lock case - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 1 x euro profile cylinder key / turn - 60mm length - matt black 3 x ball bearing hinges - 76mm x 50mm - matt black £102.20 £85.17
49220.9 - Knurled Design Lever Door Handles On Round Rose - Matt Black - Euro Profile Lock & Hinge Pack - To Suit 44mm Thick Key Locking Doors With Internal Thumbturn - FD30 Fire Rated Short Description: Suitable for use on 44mm thick FD30 fire rated internal doors, items included within this door pack are: 1 x pair of door handles - matt black 2 x euro profile escutcheon key hole covers - matt black 1 x heavy duty euro profile mortice sash lock case - 76mm case depth (57mm backset) CE / UKCA Marked - fire rated - matt black 1 x intumescent kit for euro profile sash lock 1 x euro profile cylinder key / turn - 70mm length - matt black 3 x fire rated ball bearing hinges - 102mm x 76mm - CE / UKCA Marked - fire rated - matt black 6 x intumescent hinge pad liners £134.50 £112.08

Enquire Now

Description

Knurled design round rose lever handles.
Matt black finish.
Concealed bolt through fixings via push on rose.
Tested to BS EN 1906:2012 - classification number 16-1034A - category of use grade 3
Suitable for use on fire rated doors tested to BS EN 1634
Matching accessories available including standard escutcheons (keyhole covers) and a bathroom turn & release set.

How To Order Lever Handles With A Rose

For Non-Locking Doors - 1 x (Pair) Lever Handles Only

Diagram showing levers handle only for non-locking doors

For Locking Doors - 1 x (Pair) Lever Handles Only + 2 x (Each) Standard Escutcheons

Diagram showing lever handles and standard escutcheons for locking doors

For Euro Cylinder Locking Doors - 1 x (Pair) Lever Handles Only + 2 x (Each) Euro Escutcheons

Diagram showing lever handles with euro profile escutcheon for doors locking via Euro profile cylinder

For Locking Bathroom Doors - 1 x Pair Lever Handles Only + 1 x (Set) Turn & Emergency Release

Diagram showing lever handles with a bathroom turn and emergency release set for locking bathroom doors

Matching Accessories

Standard escutcheon - (key hole cover to suit regular "chubb style locks")

Euro profile escutcheon - (key hole cover to suit euro profile cylinders)

Turn & emergency release - (a thumbturn used to lock bathroom doors, WC's and toilet doors)

Disabled large turn & emergency release - (a thumbturn used to lock bathroom doors, WC's and toilet doors)

Base Material

Made from grade 304 stainless steel.

Finish

Matt black

Operation

Both levers are sprung to ensure the lever always returns to its starting position.

Dimensions

Rose Diameter - 52mm
Rose Thickness - 7mm

Knurled Design Lever Handles On Round Rose - Dimensions

Spindle Size

8mm x 8mm square - UK Standard.

Fixings

Concealed bolt together fixings via male and female bolts.
Grub screw fixing to spindle for extra strength once fitted to the door.
Comes supplied with male and female bolt through fixings and 8mm heso fixing spindle.

Usage

Suitable for residential or commercial use.
Suitable for internal or external use.

Unit Of Sale

Lever handles are sold in pairs. (One pair consists of 1x left hand and 1x right hand).
Escutcheons (key hole covers) are sold individually (each).
Turn and emergency releases are sold as a set (One set consists of a rose with a thumbturn fitted to the inside of the door and a rose with a coin slot fitted to the outside of the door).

Download

Download PDF Data Sheet

Specification
